Beam Mount Conduit and Box Support Assembly

View as Grid List Table
ModelDescriptionMaterialMaster CartonQuantity
CBS1818 Conduit Box Support 5050
CBS18HIC1001" EMT and 3/4" Rigid/RMC, 18" Bar Support With 1/4" Star Hole and Two Mounting Holes For #6 Sms Or Tek Screw, Spring SteelSteel; Spring Steel2525
CBS18HIC100181" EMT and 3/4" Rigid/RMC, Beam Clamp  1/8-1/4" Flange, 18" Bar Support, Spring SteelPre-Galvanized Steel2525
CBS18HIC1005161" EMT and 3/4" Rigid/RMC, Beam Clamp  5/16-1/2" Flange, 18" Bar Support, Spring SteelPre-Galvanized Steel2525
CBS18HIC100APS1" EMT Clip With Multi-Functionn Clip  Spring SteelSteel; Spring Steel2525
CBS18KC12345161/2" and 3/4" Conduit, Beam Clamp  5/16-1/2" Flange, 18" Bar Support, Spring SteelSteel; Spring Steel2525
CBS18KC15161" Conduit, Beam Clamp  5/16-1/2" Flange, 18" Bar Support With Two Mounting Holes For #6 Sms Or Tek Screw, Pre-Galvanized/Spring SteelSteel; Spring Steel2525
CBS18HIC100ST1" EMT and 3/4" Rigid/RMC With 1/4"-20 x 1/2" Stud, 18" Bar Support Spring SteelSteel; Spring Steel2525
CBS18HIC501/2" EMT, 18" Bar Support With 1/4" Star Hole and Two Mounting Holes For #6 Sms Or Tek Screw, Pre-Galvanized/Spring SteelSteel; Spring Steel2525
CBS18HIC50181/2" EMT, Beam Clamp  1/8-1/4" Flange, 18" Bar Support, Spring SteelPre-Galvanized Steel2525
CBS18HIC505161/2" EMT, Beam Clamp  5/16-1/2" Flange, 18" Bar Support, Spring SteelPre-Galvanized Steel2525
CBS18HIC50APS1/2" EMT Clip With Multi Function Clip, Spring SteelSteel; Spring Steel2525
CBS18HIC50ST1/2" EMT, 1/4"-20 X 1/2" Stud, 18" Bar Support With Two Mounting Holes For #6 Sms Or Tek Screw, Pre-Galvanized/Spring SteelSteel; Spring Steel2525
CBS18HIC753/4" EMT and 1/2" Rigid/RMC, 18" Bar Support With 1/4" Star Hole and Two Mounting Holes For #6 Sms Or Tek Screw, Pre-Galvanized/Spring SteelSteel; Spring Steel2525
CBS18HIC75183/4" EMT Clip, Beam Clamp  1/8-1/4" Flange, 18" Bar Support, Spring SteelPre-Galvanized Steel2525
CBS18HIC755163/4 EMT And 1/2 RMC Clip With5/16-1/2Beam Clamp, 18" Bar Support, Spring SteelPre-Galvanized Steel2525
CBS18HIC75APS3/4 EMT Clip With 5/16 - 1/2 Bean Clamp, Spring SteelSteel; Spring Steel2525
CBS18HIC75ST1/4"-20 x 1/2" Stud,  3/4" EMT and 1/2" Rigid/RMC, 18" Bar Support, Spring SteelSteel; Spring Steel2525
CBS18KC1181" Conduit, Beam Clamp  1/8-1/4" Flange, 18" Bar Support, Spring SteelSteel; Spring Steel2525
CBS18KC1234181/2" and 3/4" Conduit, Beam Clamp  1/8-1/4" Flange, 18" Bar Support, Spring SteelSteel; Spring Steel2525
CBS18KC1ST1" Conduit, 1/4"-20 x 1/2" Stud, 18" Bar Support With Two Mounting Holes For #6 Sms Or Tek Screw, Pre-Galvanized/Spring SteelSteel; Spring Steel2525
CBS18KC38183/8" Flexible Conduit, Beam Clamp  1/8-1/4" Flange, 18" Bar Support, Spring SteelSteel; Spring Steel2525
CBS18KC385163/8" Flexible Conduit, Beam Clamp  5/16-1/2" Flange, 18" Bar Support, Spring SteelSteel; Spring Steel2525
CBS18KC38ST3/8" Flexible Conduit, 1/4"-20 x 1/2" Stud,   18" Bar Support, Spring SteelSteel; Spring Steel2525
CBS18KC38SBD1-1/2" Standoff Bracket for Decking (Complies NEC® Sec. 300.4(E)), 1/4" Mounting Holes, Pre-Galvanized Steel; Closed Conduit Clip, Fits 3/8" Conduit,2525
CBS18KC1SBD1-1/2" Standoff Bracket for Decking (Complies NEC® Sec. 300.4(E)), 1/4" Mounting Holes, Pre-Galvanized Steel; Closed Conduit Clip, Fits 1" Conduit.2525
